Product Details
- Size: L*W*H(mm) 5827X2150X3019
- Place of Origin: china
- Brand Name: ENSIGN
- Model Number: YX620
- Weight: 6200.000 kg
- :
- :
- :
| Technical Parameters | |||
| Bucket capacity(m³) | 1.0 | Total cycle time(lift,dump&lower) | ≤9s |
| Rated load | 1800kg | Dump height/Dump angle | 2518mm/44° |
| Overall operating weight | 6200kg | Dump distance/Dump angle | 946mm/44° |
| Max. traction force | ≥56kN | Min.ground clearance | 293mm |
| Max.breakout force | ≥58kN | Wheel base | 2260mm |
| Gradeability | 30° | Wheel tread | 1630mm |
| Min.turning radius(outer side of the bucket) | 5143mm | Departure angle | 30° |
| Min.turning radius(outer side of the tire) | 4661mm | Steering angle(left&right) | 35° |
| Overrall dimension(standard configuration) (mm) | 5827*2150*3019 | ||
| Model | YC4D80-T20 | ||
- Size: L*W*H(mm) 5827X2150X3019
- Place of Origin: china
- Brand Name: ENSIGN
- Model Number: YX620
- Weight: 6200.000 kg
- :
- :
- :
