Product Details
- Size: L*W*H (mm) 8725X3080X3500
- Place of Origin: china
- Brand Name: ENSIGN
- Model Number: YX667
- Weight: 20120.000 kg
- :
- :
- :
| Technical Parameters | |||
| Bucket capacity(m³) | 3.5 | Total cycle time(lift,dump&lower) | ≤10.6s |
| Rated load | 6000kg | Dump height/Dump angle | 3010mm/45° |
| Overall operating weight | 20120kg | Dump distance/Dump angle | 1250mm/45° |
| Max. traction force | ≥186kN | Min.ground clearance | 445mm |
| Max.breakout force | ≥186kN | Wheel base | 3350mm |
| Gradeability | 30° | Wheel tread | 2250mm |
| Min.turning radius(outer side of the bucket) | 7088mm | Departure angle | 30° |
| Min.turning radius(outer side of the tire) | 6287mm | Steering angle(left&right) | 38° |
| Overrall dimension(standard configuration) (mm) | 8725*3080*3500 | ||
| Model | Weichai WP10G240E321 | ||
- Size: L*W*H (mm) 8725X3080X3500
- Place of Origin: china
- Brand Name: ENSIGN
- Model Number: YX667
- Weight: 20120.000 kg
- :
- :
- :
