Product Details
- Size: L*W*H (mm) 7930X3024X3480
- Place of Origin: china
- Brand Name: ENSIGN
- Model Number: YX657
- Weight: 16500.000 kg
- :
- :
- :
| Technical Parameters | |||
| Bucket capacity(m³) | 2.4~4.5(standard bucket2.8) | Total cycle time(lift,dump&lower) | ≤11s |
| Rated load | 5000kg | Dump height/Dump angle | 3175mm/51° |
| Overall operating weight | 16500kg | Dump distance/Dump angle | 1126mm/51° |
| Max. traction force | ≥160kN | Min.ground clearance | 445mm |
| Max.breakout force | ≥190kN | Wheel base | 3200mm |
| Gradeability | 30° | Wheel tread | 2190mm |
| Min.turning radius(outer side of the bucket) | 6652mm | Departure angle | 30° |
| Min.turning radius(outer side of the tire) | 6038mm | Steering angle(left&right) | 38° |
| Overrall dimension(standard configuration) (mm) | 7930*3024*3480 | ||
| Model | Shangchai SC11CB220G2B1 | ||
- Size: L*W*H (mm) 7930X3024X3480
- Place of Origin: china
- Brand Name: ENSIGN
- Model Number: YX657
- Weight: 16500.000 kg
- :
- :
- :
